☔ IP68 rated
🍃 Wind-resistance 136.7 mph (220 km/h)
🚑 With two cellular channels, two Wi-Fi channels, and a high-gain LNA GPS, the Mobility 22G is a versatile, all-in-one cellular antenna solution.
🚌 It has 2×2 MIMO and dual-band Wi-Fi for high bandwidth and solid reliability.
$249.00
The Peplink Mobility 22G is a 5-in-1 antenna built for mobile applications. It supports 2×2 cellular MIMO for high bandwidth and solid reliability, dual-band (2.4GHz & 5GHz) Wi-Fi, and GPS. It is also 5G-ready and supports a wide range of global cellular frequencies. The GPS receiver is equipped with high-gain LNA, making it ideal for location tracking.
The Mobility 22G has a solid housing made of UV-stable plastic materials (PC +ABS). Two color options are available (black and white) to fit different deployments. For easier installation, the antenna comes with different cable length options.
5G can reach speeds 10× faster than 4G LTE. Download movies in seconds.
Certified quality protection from dust, water, and UV allows you to use it even in poor weather conditions.
Supports extended bandwidth range, including B71.
Increased signal strength for a stronger connection and less interference.
| Weight | 1.5 lbs |
|---|---|
| Dimensions | 5.12 × 1.42 × 0.2 in |
| Brand | Peplink |
| Model Number | ANT-MB-22G-S-B-6 |
| Dimensions | 130 mm × 36 mm (5.12 in. × 1.42 in.) |
| Temperature | –40 °C to 80 °C (–40 °F to 176 °F) |
| Antenna Placement | External Antennas |
| Antenna Technology | Cellular, 5G, 5G/4G MIMO, LTE, LTE MIMO, GPS, Wi-Fi |
| Antenna Frequency | 1400–6000 MHz, 2.4 GHz, 2.4/5.8 GHz, 5 GHz, 4G Bands, 5G Bands |
| 4G/LTE/3G Frequency Band | Band 1 (2100 MHz), Band 2 (1900 MHz), Band 3 (1800 MHz), Band 4 (AWS: 1700/2100 MHz), Band 5 (850 MHz), Band 6 (800 MHz), Band 7 (2600 MHz), Band 8 (900 MHz), Band 9 (1700/1800 MHz), Band 11 (1500 MHz), Band 12 (700 MHz), Band 13 (700 MHz), Band 14 (700 MHz), Band 17 (700 MHz), Band 18 (850 MHz), Band 19 (850 MHz), Band 20 (800 MHz), Band 21 (1500 MHz), Band 24 (1600 MHz), Band 25 (1900 MHz), Band 26 (850 MHz), Band 27 (450 MHz), Band 28 (700 MHz), Band 66 (1700/2100 MHz), Band 71 (600 MHz), Band 85 (700 MHz) |
| Mounting | Screw Mount, Vehicle Mount |
| Cable Length | 2 m (6.6 ft) |
| Antenna Connector | SMA (M) Straight, RP-SMA (M) Straight |
| Color | Black |
| Certifications | REACH (EU), RoHS (EU), WEEE (EU) |
| Antenna Type | Dome (Panel Mount) |
| Antenna Frequency Type | 5-in-1, 5G/LTE, 4G LTE/3G Cellular, Multi-Band Wi-Fi, 2.4 GHz, 2.4/5 GHz, 5.X GHz |
| Gain | 6 dBi |
| Connector Type | SMA(M) (LTE and GPS) and RP-SMA(M) (Wi-Fi) |
| Material Connector | PC+ABS |
| Nominal Impedance | 50Ω |
| Polarization | Linear |
| Power | 10W |
| Center Frequency | 600–6000 MHz |
| VSWR | <2.5 |
| Form Factor | Wall/Ceiling Mount |
| Sub-Type | Wall/Panel Mount |
| Efficiency | 0.85 |
| Antenna Application | Public Safety |
