☔ IP68 rated
🍃 Wind-resistance 136.7 mph (220 km/h)
🚑 With four cellular channels, two Wi-Fi, and one GPS, the Mobility 42G provides ultrawide bandwidth within a single antenna housing.
🚌 The Mobility 42G is designed for heavy network usage and solid reliability.
$299.00
5G can reach speeds 10× faster than 4G LTE. Download movies in seconds.
Certified quality protection from dust, water, and UV allows you to use it even in poor weather conditions.
Supports extended bandwidth range, including B71.
Increased signal strength for a stronger connection and less interference.
| Weight | 2.5 lbs |
|---|---|
| Dimensions | 8.19 × 2.28 × 0.32 in |
| Brand | Peplink |
| Model Number | ANT-MB-42G-S-B-6 |
| Dimensions | 208 mm × 58 mm (8.19 in. × 2.28 in.) |
| Temperature | –40 °C to 80 °C (–40 °F to 176 °F) |
| Antenna Placement | External Antennas |
| Antenna Technology | Cellular, 5G, 5G/4G MIMO, LTE, LTE MIMO, GPS, Wi-Fi |
| Antenna Frequency | 2.4 GHz, 2.4/5.8 GHz, 5 GHz, 4G Bands, 5G Bands |
| 4G/LTE/3G Frequency Band | Band 1 (2100 MHz), Band 2 (1900 MHz), Band 3 (1800 MHz), Band 4 (AWS: 1700/2100 MHz), Band 5 (850 MHz), Band 6 (800 MHz), Band 7 (2600 MHz), Band 8 (900 MHz), Band 9 (1700/1800 MHz), Band 11 (1500 MHz), Band 12 (700 MHz), Band 13 (700 MHz), Band 14 (700 MHz), Band 17 (700 MHz), Band 18 (850 MHz), Band 19 (850 MHz), Band 20 (800 MHz), Band 21 (1500 MHz), Band 24 (1600 MHz), Band 25 (1900 MHz), Band 26 (850 MHz), Band 27 (450 MHz), Band 28 (700 MHz), Band 66 (1700/2100 MHz), Band 71 (600 MHz), Band 85 (700 MHz) |
| Mounting | Screw Mount, Vehicle Mount |
| Cable Length | 2 m (6.6 ft) |
| Antenna Connector | SMA (M) Straight, RP-SMA (M) Straight |
| Color | Black |
| Certifications | REACH (EU), RoHS (EU), WEEE (EU) |
| Antenna Type | Dome (Panel Mount) |
| Antenna Frequency Type | 7-in-1, 5G/LTE, 4G LTE/3G Cellular, Multi-Band Wi-Fi, 2.4 GHz, 2.4/5 GHz, 5.X GHz |
| Gain | 8 dBi |
| Connector Type | SMA(M) (LTE and GPS) and RP-SMA(M) (Wi-Fi) |
| Material Connector | PC |
| Nominal Impedance | 50Ω |
| Polarization | Linear |
| Power | 10W |
| Center Frequency | 617–6000 MHz |
| VSWR | <2.5 |
| Form Factor | Wall/Ceiling Mount |
| Sub-Type | Wall/Panel Mount |
| Efficiency | 0.95 |
| Antenna Application | Public Safety |
