Aluminum reflector material
Gain:
2.5 dBi at 698–960 MHz
3.5 dBi at 1710–2700 MHz
$32.00
| Weight | 0.75 lbs |
|---|---|
| Dimensions | 6.69 × 7.09 × 7.09 in |
| VSWR | <1.8 at 698–960 MHz; <1.5 at 1710–2700 MHz |
| Polarization | Vertical |
| Brand | Nextivity |
| Model Number | A11-V43-100 |
| Dimensions | 170 mm × 180 mm × 180 mm (6.69 in. × 7.09 in. × 7.09 in.) |
| Temperature | –40 °C to 65 °C (–40 °F to 149 °F) |
| Antenna Placement | External Antennas |
| Antenna Technology | Cellular, 4G/3G/2G, LTE |
| Antenna Frequency | 698–960 MHz, 960 MHz, 1710–2690 MHz, 1710–6000 MHz |
| Mounting | Ceiling Mount, Screw Mount |
| Cable Length | 2 m (6.6 ft) |
| Antenna Connector | SMA (M) Straight |
| Color | White |
| Antenna Type | Omni (Omni-Directional) |
| Antenna Frequency Type | 4G LTE/3G Cellular |
| Gain | 2 dBi, 3 dBi |
| Connector Type | SMA Male |
| Material Connector | ABS |
| Nominal Impedance | 50 Ω |
| Power | 50 W |
| Horizontal Beamwidth | 360° |
| Vertical Beamwidth | 90°/55° |
| Style Type | Omni-Directional |
| Center Frequency | 698–960 MHz/1710–2700 MHz |
| Form Factor | Indoor Omni |
| Sub-Type | Omni |
