Max input power 33 dBm
Gain:
2.2 dBi at 500 MHz
2.5 dBi at 720 MHz
3.3 dBi at 840 MHz
3.3 dBi at 1750 MHz
3.8 dBi at 1900 MHz
3.8 dBi at 2150 MHz
$296.00
The SHIELD Active Server Antenna is an active multi-frequency, omnidirectional antenna for ERCES that require monitoring capabilities at the component level. In addition to being designed for hard cap and false ceilings, the Active Server Antenna features an N-type female connector and rugged IP20 grade electronics. The component is ideal for SHIELD EXTEND and SHIELD SOLO installations, providing real-time antenna monitoring capabilities through the Nextivity WAVE Portal.
| Weight | 1 lbs |
|---|---|
| Dimensions | 9.53 × 9.53 × 2.09 in |
| Brand | Nextivity |
| Model Number | A33-10A-100 |
| Dimensions | ⌀242 mm × 53 mm (⌀9.53 in. × 2.09 in.) |
| Temperature | –20 °C to 50 °C (–4 °F to 122 °F) |
| Antenna Placement | External Antennas |
| Antenna Technology | LTE |
| Antenna Frequency | 450 MHz, 700 MHz, 800 MHz, 4G Bands |
| 4G/LTE/3G Frequency Band | Band 2 (1900 MHz), Band 4 (AWS: 1700/2100 MHz), Band 12 (700 MHz), Band 14 (700 MHz) |
| Mounting | Ceiling Mount, Screw Mount |
| Antenna Connector | N-Type (F) |
| Color | White |
| Antenna Type | Omni (Omni-Directional) |
| Antenna Frequency Type | 4G LTE/3G Cellular |
| Gain | 2 dBi, 3 dBi |
| Connector Type | N Type Female |
| Material Connector | ASA |
| Nominal Impedance | 50 Ω |
| Polarization | Horizontal |
| Style Type | Omni-Directional |
| Center Frequency | 450 MHz/700 MHz/800 MHz/1700-2100 MHz/1900 MHz |
| Form Factor | Outdoor Omni |
| Sub-Type | Omni |
| Antenna Application | Public Safety |
