Tycon TP-SCPOE-1248 PoE and Solar Charge Controllers | 12 V In / 48 V Out
Tycon TP-SCPOE-1248 PoE and Solar Charge Controllers | 12 V In / 48 V Out - Image 2
Tycon TP-SCPOE-1248 PoE and Solar Charge Controllers | 12 V In / 48 V Out - Image 3

Tycon TP-SCPOE-1248 PoE and Solar Charge Controllers | 12 V In / 48 V Out

🌞 Dual charging capability: Charges batteries from solar panels and Passive PoE, ensuring reliable power availability.

🛡️ Comprehensive protection: Offers electronic protections including short circuit, reverse current, overvoltage, overcharge, and over-discharge safeguards.

💡 User-friendly indicators: Features five LED indicators to easily monitor power source, battery status, and system health.

📏 Compact design: A small form factor with low power consumption, suitable for various remote applications such as surveillance and wireless stations.

$164.00

Related Products

Description

The TP-SCPOE Charge Controller by Tycon Solar® is a versatile device designed for efficient remote power system power management. It features dual inputs for charging 12 V or 24 V batteries using solar panels and Passive PoE, making it ideal for surveillance, sensors, wireless stations, and UPS systems.

Key features

  • Dual-input charging: Supports charging from solar panels and Passive PoE, offering redundancy for continuous power supply.
  • Robust protections: Includes safeguards against short circuits, reverse current, overvoltage, overcharge, and over-discharge.
  • Compact and durable: Designed for high-temperature operation with low self-consumption, making it suitable for challenging environments.
  • Visual indicators: Equipped with LED indicators for quick status checks of power source, battery charging, load output, and more.

Additional information

Weight 1.25 lbs
Dimensions 11 × 7 × 2 in
Brand

Tycon
Model Number

TP-SCPOE-1248
Product Family

Cables and Accessories
Accessory Type

Charger
Operation Voltage

48 V
Dimensions

160 mm × 117 mm × 41 mm (6.3 in. × 4.6 in. × 1.6 in.)
Input Power

15 to 36 V (Solar), 18 to 57 V (PoE)
Interface

PoE
Temperature

–30 °C to 60 °C (–22 °F to 140 °F)
