VIA Technologies ATG-A900-1D10A1 Embedded PC | VIA Elite E1000

Description

Ultra compact fanless Android signage system with extended I/O
support

• VIA Elite E1000 ARM Cortex-A9 Dual Core processor with 1GHz
  Frequency and 512KB cache SoC
• Support Wake-on LAN
• Android system with device management capabilities:
• Watchdog Timer
• System Power off
• System Reboot
• Auto Power on
• Remote monitoring

• System Memory
• 2GB DDR3-1333MHz SDRAM using 512MB x 8 Banks x 4pcs
• Onboard Storage
• 4GB eMMC Flash
• 1× mSATA slot
• Graphic
• Unified Shader Architecture with 64 stream processors
• Open GL ES 3.0/2.0, OpenVG 1.1, OpenCL 1.1 embedded,
  DX11_Level_9.3
• Fix function 2D with HW rotation and overlay
• Elite E1000 Feature Decoding engine:
• H.264 HP @ L4.2
• VC1 AP @ L3.0
• MPEG-4 ASP @ L5
• MPEG-2 MP @ HL
• JPEG and Motion JPEG baseline profile
• AVS+ JiZhun Profile @ L6.0
• AVS+ Broadcasting profile @ Level 6.0.0.08.60
• WebM (up to 1920×1080 @ 30Hz)
• H.264-MVC
• Maximum Bitrate up to 120 Mbps for MPEG-2, 40Mbps for MPEG-4
  , 15Mbps for WebM and 100Mbps for H.264/VC-1, 80Mbps for AVS+
• Encoding engine:
• H.264: CABAC/CAVLC; MP @ L4.0 1920x1080p @ 30Hz
• Onboard Audio
• WOLFSON WM8960 Audio Codec
• Onboard Power Management IC’s
• WOLFSON WM8326GEFL/RV processor power management subsystem
• Onboard EEPROM
• Support FLASH ROM M25P32-VMW6G 32Mbit/4MB SO8W 8PIN for boot
  loader
• Mini-PCIe
• 1× Mini-PCIe slot support ZU200 3.75G UMTS/HSPA 3G module
  (optional)
