☔ IP66 rated
🌡 Designed for high temperatures
$89.99
The Dragino LTC2-HT Industrial LoRaWAN Temperature Transmitter is designed to monitor high temperatures. Through a PT100 probe, the LTC2-HT measures temperature and uplinks it to the IoT server via LoRaWAN protocol.
The LTC2-HT has a datalog feature that records data even when there is no network coverage, allowing users to retrieve the logged sensor values via the LoRaWAN downlink command.
The LTC2-HT is powered by 8500 mAh Li-SOCl₂ battery that can run 2~10 years depends on the network environment and working mode. Each LTC2-HT has two internal 16-bit ADC interfaces calibrated on 12 set resistors to ensure accurate measurements over a wide range of temperatures.
The LTC2-HT is LoRaWAN v1.0.3 compatible. Each LTC2-HT comes preloaded with a set of unique keys for LoRaWAN registrations, and registering these keys to a local LoRaWAN server will cause it to automatically connect after powering on.
| Weight | 1 lbs |
|---|---|
| Dimensions | 4.72 × 2.17 × 7.87 in |
| Brand | Dragino |
| Model Number | LTC2-HT |
| Dimensions | 120 mm × 55 mm × 200 mm (4.72 in. × 2.17 in. × 7.87 in.) |
| Temperature | –40 °C to 85 °C (–40 °F to 185 °F) |
| Sensor Form Factor | Sensor |
| Application | Condition Monitoring |
| Technology | LoRaWAN |
| Sensor Type | Temperature |
| Power | 8500 mAh Li/SOCl₂ Battery |
| Battery Life | 2-10 Years |
| Warranty | 2 Years |
