$34.00
![SparkLAN WUBT-239ACN(BT)[P4W] USB (Wafer) | Dual-band 802.11ac/abgn + BT | 2×2 Printed Antenna | Realtek RTL8822CU](https://i0.wp.com/embeddedworks.net/wp-content/uploads/2024/04/wlan873.jpg?fit=300%2C211&ssl=1)
![SparkLAN WUBT-239ACN(BT)[MU] USB (Type A) | Dual-band 802.11ac/abgn + BT | 2×2 u.FL/I-PEX | Realtek RTL8822CU](https://i0.wp.com/embeddedworks.net/wp-content/uploads/2024/04/wlan874.jpg?fit=300%2C109&ssl=1)
![SparkLAN WUBT-239ACN(BT)[M4W] USB (Wafer) | Dual-band 802.11ac/abgn + BT | 2×2 u.FL/I-PEX | Realtek RTL8822CU](https://i0.wp.com/embeddedworks.net/wp-content/uploads/2024/04/wlan875.jpg?fit=300%2C141&ssl=1)
SparkLAN WUBT-239ACN(BT) is a highly integrated single-chip Wireless LAN (WLAN), Bluetooth USB module which supports 2 streams 802.11ac solutions with multi-user MIMO wireless LAN and integrated Bluetooth 5.0. It is integrated 2T×2R WLAN MAC, baseband, and dual-band RF in a single-chip USB module. WUBT-239ACN(BT) provides a cost-effective solution for M2M connectivity product/device by one USB port.
| Weight | 0.1 lbs |
|---|---|
| Dimensions | 2.17 × 0.79 × 0.18 in |
| Temperature | Operating: –20 °C to 70 °C; Storing: –40 °C to 85 °C |
| Chipset Maker | Realtek |
| Interface Connector | USB Type A |
| RF Connector | Printed Antenna |
| Brand | SparkLAN |
| Model Number | WUBT-239ACN(BT)[PU] |
| Dimensions | 55.07 mm × 20.02 mm × 4.5 mm (2.17 in. × 0.79 in. × 0.18 in.) |
| WLAN Form Factor | USB (Type A) |
| Chipset Model | RTL8822CU |
| Chipset | Realtek RTL8822CU |
| Wi-Fi Frequency | Dual-Band |
| Wireless Standard | 802.11ac/abgn + BT |
| MIMO | 2×2 |
| Host Interface | USB |
| RF Output Summary | 17 dBm |
| Certifications | CE (EEA), FCC (US), IC (CA), REACH (EU), RoHS (EU), TELEC (JP) |
| Warranty | 1 Year |
