Lead time is 12–16 weeks
$36.00
The WMX7206 module is a highly integrated wireless local area network (WLAN) mini PCIe module, based on Realtek RTL8852BE and supporting 802.11ax Wi-Fi and Bluetooth (BT).
| Weight | 0.05 lbs |
|---|---|
| Dimensions | 1.18 × 1.18 × 0.11 in |
| Temperature | Operating: –40 °C to 85 °C (–40 °F to 185 °F); Storing: –40 °C to 105 °C (–40 °F to 221 °F) |
| Interface Connector | WLAN: mPCIe v2.1; Bluetooth v5.2: USB |
| Chipset Maker | Realtek |
| Interface Connector | USB, mPCIe |
| RF Connector | u.FL/I-PEX |
| Brand | EmWicon |
| Model Number | WMX7206 |
| Dimensions | 29.9 mm × 30 mm × 2.8 mm (1.18 in. × 1.18 in. × 0.11 in.) |
| WLAN Form Factor | mPCIe (Half-Size) |
| Chipset Model | RTL8852BE |
| Chipset | Realtek RTL8852BE |
| Wi-Fi Frequency | Dual-Band |
| MIMO | 2×2 |
| Wireless Standard | 802.11ax (Wi-Fi 6) + BT |
| Host Interface | PCI, USB |
| Certifications | CE (EEA), FCC (US), IC (CA), RED (EU) |
