EmWicon WMU7212 mPCIe (Half-Size) | 802.11ax (Wi-Fi 6E) + BT | 2×2 u.FL/I-PEX | Realtek RTL8852CU
EmWicon WMU7212 mPCIe (Half-Size) | 802.11ax (Wi-Fi 6E) + BT | 2×2 u.FL/I-PEX | Realtek RTL8852CU - Image 2
EmWicon WMU7212 mPCIe (Half-Size) | 802.11ax (Wi-Fi 6E) + BT | 2×2 u.FL/I-PEX | Realtek RTL8852CU - Image 3

EmWicon WMU7212 mPCIe (Half-Size) | 802.11ax (Wi-Fi 6E) + BT | 2×2 u.FL/I-PEX | Realtek RTL8852CU

$33.95

  • Note: The listed price includes all applicable import duties and tariffs—no hidden fees at checkout.

Description

The WMU7212 is based on the Realtek RTL8852CU chip, a highly integrated single-chip that supports two-stream 802.11ax solutions with multi-user MIMO (multiple-input, multiple-output), wireless LAN (WLAN), and integrated Bluetooth 5.2 USB in one module.

It combines a WLAN MAC, a 2T2R-capable WLAN baseband, and RF in a single module. The WMU7212 provides a complete solution for a high-performance integrated wireless and Bluetooth device.

Additional information

Weight 0.05 lbs
Dimensions 1.18 × 1.06 × 0.09 in
Chipset Maker

Realtek
Interface Connector

mPCIe (Half)
RF Connector

u.FL/I-PEX
Brand

EmWicon
Model Number

WMU7212
Dimensions

29.85 mm × 26.8 mm × 2.35 mm (1.18 in. × 1.06 in. × 0.09 in.)
WLAN Form Factor

mPCIe (Half-Size)
Chipset Model

RTL8852CU
Chipset

Realtek RTL8852CU
Wi-Fi Frequency

Tri-Band
MIMO

2×2
Wireless Standard

802.11ax (Wi-Fi 6E) + BT
Host Interface

USB
Certifications

CE (EEA), FCC (US), IC (CA), RED (EU)
