$33.95
The WMU7213 is based on the Realtek RTL8852CU chip, a highly integrated single-chip that supports two-stream 802.11ax solutions with multi-user MIMO (multiple-input, multiple-output), wireless LAN (WLAN), and integrated Bluetooth 5.2 USB in one module.
It combines a WLAN MAC, a 2T2R-capable WLAN baseband, and RF in a single module. The WMU7213 provides a complete solution for a high-performance integrated wireless and Bluetooth device.
| Weight | 0.05 lbs |
|---|---|
| Dimensions | 1.18 × 0.87 × 0.11 in |
| Chipset Maker | Realtek |
| Interface Connector | M.2 (2230) |
| RF Connector | u.FL/I-PEX |
| Brand | EmWicon |
| Model Number | WMU7213 |
| Dimensions | 30 mm × 22 mm × 2.8 mm (1.18 in. × 0.87 in. × 0.11 in.) |
| WLAN Form Factor | M.2 (2230) |
| Chipset Model | RTL8852CU |
| Chipset | Realtek RTL8852CU |
| Wi-Fi Frequency | Tri-Band |
| MIMO | 2×2 |
| Wireless Standard | 802.11ax (Wi-Fi 6E) + BT |
| Host Interface | USB |
| Certifications | CE (EEA), FCC (US), IC (CA), RED (EU) |
