Ericsson Cradlepoint IBR1700 Cat 6 Router (600 Mbps Modem) | MA1-1700600M-NNA | 1-Year NetCloud Mobile Essentials Plan

Description

With 802.11ac Wave 2 Wi-Fi, ideal for in-vehicle networks. Now with CAT6 (LTE Advanced 600 Mbps DL) speed and a 3-year warranty. This unit does NOT include the AC/DC power adapter or antennas, just the DC power cable.

The IBR1700 is a compact, ruggedized 3G/4G/LTE networking solution for mission-critical connectivity. The NetCloud cloud-managed solution allows organizations to scale deployments quickly and manage their vehicle networks in real time. With an extensive list of safety and hardening certifications(now with FIPS 140-2), it is engineered to protect against extreme environmental conditions.

4G LTE with 2DL and 3DL carrier aggregation, provides up to 600 Mbps download speed! Uplink at 75 Mbps.

Enterprise performance

Targeted for heavy-duty, in-vehicle applications such as fire, ambulance, and police, as well as group-transportation solutions.
Additional open slot for MC400 (dual-modem) applications.
Cloud-managed.
Gigabit Wi-Fi, dual-band, dual concurrent Wi-Fi (802.11 a/b/g/n/ac wave 2).
Ruggedized for vibration, shock, dust, splash, and humidity.
Ignition sensing.
Certified 3G/4G/LTE enterprise-grade internal modems.
Software-defined radio supports multiple carriers, SIM-based auto-carrier selection.
Built-in transient and reverse polarity voltage protection.
9–36 V DC voltage input range.
Integrated temperature sensor. 2× analog inputs, 4× config. I/O, ignition sense.
Active GPS support.
5× LAN/WAN ports.

Note: Antennas are NOT included with the router.

Additional information

Weight	2 lbs
Dimensions	8.82 × 7.48 × 1.73 in
Frequency	4G LTE: Band 1–5, 7, 8, 12, 13, 17, 20, 25, 28–30, 40, 41, 66; 2DL and 3DL support for AT&T, T-Mobile, and Verizon
Interface Connector	RJ-45
Model Number	IBR1700-600M-bundle
Brand	Ericsson
Dimensions	224 mm × 190 mm × 44 mm (8.8 in. × 7.5 in. × 1.7 in.)
Temperature	–20 °C to 70 °C (–4 °F to 158 °F)
Product Family	Ericsson Cradlepoint IBR900
Product Type	Router
Device Form Factor	Router: Outdoor/Rugged
Cellular Technology	4G LTE Cat 6 with Fallback
4G/LTE/3G Frequency Band	Band 1 (2100 MHz), Band 2 (1900 MHz), Band 3 (1800 MHz), Band 4 (AWS: 1700/2100 MHz), Band 5 (850 MHz), Band 7 (2600 MHz), Band 8 (900 MHz), Band 12 (700 MHz), Band 13 (700 MHz), Band 17 (700 MHz), Band 20 (800 MHz), Band 25 (1900 MHz), Band 28 (700 MHz), Band 29 (700 MHz), Band 30 (2300 MHz), Band 40 (2300 MHz), Band 41 (2500 MHz), Band 66 (1700/2100 MHz)
Carrier	AT&T, T-Mobile, Verizon
Coverage Region	North America
Features	Ruggedized/Vehicle with GPS and Wi-Fi
Power	9 to 24 V DC
I/O Interface	5× GbE (WAN/LAN Switchable), Wi-Fi (802.11 a/b/g/n/ac Wave 2), 4× GPIO, 2× A/D
RF Connector	6× MIMO Wi-Fi (RP-SMA-F), 2× LTE, 1× GPS (SMA-F)
Certifications	CE (EEA), FCC (US), IC (CA), RoHS (EU)
Carrier Approvals	AT&T, Verizon
