🔥 High Performance 5G and Wi-Fi 6: Equipped with 5G, 2×2 MIMO Wi-Fi 6 (Optional), 5Gbps Ethernet, and 1200 Mbps theoretical peak Wi-Fi throughput.
💪 Rugged and Compact Design: World’s smallest rugged 5G router, ideal for space-constrained environments with IP64 rating and MIL-STD-810H compliance for shock, vibration, and thermal shock.
💻 Versatile Connectivity: Features include 1 x Ethernet RJ45 (1 Gbps) or 2 x Ethernet RJ45 (1×1 Gbps + 1×5 Gbps), USB 3.2 Gen 1 Type-C with power delivery, and Dual RS-232/485 serial variants.
🔒 Advanced Security: Supports WPA2/3 Personal, WPA2/3 Transitional, WPA2 Enterprise Wi-Fi security, and VPN features including AES128/192/256 encryption and SHA256/384/512 hashing.
📅 AirLink Complete for 5 Years: Includes 5 years of hardware warranty, expert technical support, and remote device management through AirLink Management Service (ALMS).
$1,299.00
The Semtech AirLink XR60 + WiFi (MPN 1105161) is heralded as the world’s smallest rugged 5G router, designed for high-performance mobile and industrial applications where space is a constraint. This ultra-compact device is equipped with advanced technologies, including 5G cellular connectivity, optional 2×2 MIMO Wi-Fi 6, 5Gbps Ethernet, and USB-C. Its high-performance capabilities make it ideal for rapidly deploying mission-critical applications, ensuring reliable and secure data-driven transformation via cellular IoT. The XR60 is engineered to withstand harsh environments, evidenced by its robust Sealed Aluminum Housing with an IP64 rating and compliance with the MIL-STD-810H specification for shock, vibration, thermal shock, and humidity. This makes it a dependable solution for fleet vehicles, remote industrial sites, and other demanding settings. It operates across a wide temperature range, from -40°C to +75°C (-40°F to +167°F), or -30°C to +70°C (-22°F to +158°F) for the Wi-Fi variant, and features a dual-band 40 Channel GNSS for location tracking.
The AirLink XR60 is built on the AirLink OS and integrates seamlessly with the AirLink Management Service (ALMS), offering comprehensive remote management and security features. Security is paramount, with features like Wi-Fi 802.1x/Radius authentication, a stateful firewall with port forwarding and DMZ capabilities, and secure firmware updates. For VPN, it offers 175 Mbps IPSec VPN TCP throughput and integrates with VPN servers using IPsec protocols (IKEv1/IKEv2), featuring FIPS 140-2 Level 1 compliance and strong encryption (AES128/AES192/AES256) and hashing (SHA256/SHA384/SHA512). The device supports advanced edge computing via Docker Containerized Applications licensed through ALMS, powered by a Quad Core Arm A53 64-bit CPU, 1.2 GB RAM, and 750 MB Flash storage. The flexibility in connectivity is notable, offering either a Single Serial/Single Ethernet (1 Gbps) configuration or a Dual Ethernet variant (1x 1 Gbps + 1x 5 Gbps). The optional Wi-Fi 6 supports up to 32 clients, triple SSIDs, and a theoretical peak throughput of 1200 Mbps with Single 2×2 MIMO. Furthermore, the product includes 5 years of AirLink Complete service when registered in ALMS, providing hardware warranty, technical support, and secure remote management, ensuring long-term network reliability and optimization for users relying on AT&T, T-Mobile, and Verizon carriers. Its physical characteristics include dimensions of 118 x 39 x 98 mm and a weight of 522 g (with Wi-Fi), making it an extremely compact yet feature-rich 5G solution.
| Weight | 1.5 lbs |
|---|---|
| Dimensions | 4.6 × 1.5 × 3.9 in |
| Included Items | XR60, DC Power Cable, Quick Start Guide, AirLink Complete Leaflet |
| Brand | Sierra Wireless |
| Model Number | 1105161 |
| Dimensions | 118 mm × 39 mm × 98 mm (4.6 in. × 1.5 in. × 3.9 in.) |
| Temperature | Operating: –40 °C to 70 °C (–40 °F to 158 °F); Storage: –40 °C to 85 °C (–40 °F to 185 °F) |
| Product Family | Semtech XR |
| Product Type | Router |
| Device Form Factor | Router: Outdoor/Rugged |
| Cellular Technology | 5G with Fallback |
| 4G/LTE/3G Frequency Band | Band 1 (2100 MHz), Band 2 (1900 MHz), Band 3 (1800 MHz), Band 5 (850 MHz), Band 7 (2600 MHz), Band 8 (900 MHz), Band 12 (700 MHz), Band 13 (700 MHz), Band 14 (700 MHz), Band 18 (850 MHz), Band 20 (800 MHz), Band 25 (1900 MHz), Band 26 (850 MHz), Band 28 (700 MHz), Band 29 (700 MHz), Band 30 (2300 MHz), Band 38 (2600 MHz), Band 40 (2300 MHz), Band 41 (2500 MHz), Band 48 (3500 MHz), Band 66 (1700/2100 MHz), Band 71 (600 MHz) |
| 5G Frequency Band | Band N29* (700 MHz), Band N1 (2100 MHz), Band N2 (1900 MHz), Band N3 (1800 MHz), Band N5 (850 MHz), Band N7 (2600 MHz), Band N8 (900 MHz), Band N12 (700 MHz), Band N13 (700 MHz), Band N14 (700 MHz), Band N18 (700 MHz), Band N20 (800 MHz), Band N25 (1900 MHz), Band N26 (850 MHz), Band N28 (700 MHz), Band N30 (2300 MHz), Band N38 (2600 MHz), Band N40 (2300 MHz), Band N41 (2500 MHz), Band N48 (3500 MHz), Band N66 (1700/2100 MHz), Band N71 (600 MHz) |
| Carrier | AT&T, FirstNet, T-Mobile, Telus, Verizon |
| Wireless Standard | 802.11ax (Wi-Fi 6) |
| Carrier Approvals | AT&T, Bell, FirstNet 4G Capable, FirstNet Trusted with 5G Support, Rogers, Southern Linc, Telstra, Telus, T-Mobile, T-Mobile T-Priority, Verizon, Verizon Frontline Verified, Verizon Frontline Network Slice |
| Coverage Region | Global |
| Tracker Type | Hardwired, Stationary |
| Features | 5G, 2×2 MIMO Wi-Fi 6, Dual Ethernet (1 Gbps + 5 Gbps), USB 3.2 Gen 1 Type-C, IP64 Rated, Dual-band 40 Channel GNSS, Dual RS-232/485, 1 GPIO, AirLink OS, AirLink Management Service (ALMS) |
| Frequency | 5G: n1/n5/n2/n8/n18/n13/n14/n25/n28/n20/n29/n26/n12/n66/n48/n71/n38/n41/n30/n7;4G: B1/B5/B2/B8/B18/B13/B14/B25/B28/B20/B29/B26/B12/B66/B48/B71/B38/B41/B30/B7/B40;3G: B1/B5/B2/B8 |
| Chipset | ARM 8, Qualcomm X55 EM9190 |
| Power | 7 to 36 VDC Input Voltage, Idle: 3.5 W, Standby: 55 mW, 21 dBm per chain Wi-Fi Output Power |
| LAN Ports | 1 |
| WAN Ports | 2 |
| I/O Interface | 1 GPIO, USB 3.2 Gen 1 Type-C, Ethernet, Dual RS-232/485 (Serial/Ethernet variant) |
| RF Connector | SMA, SMA (Reverse Polarity), RP-SMA |
| Certifications | E-Mark (EU), REACH (EU), RoHS (EU), WEEE (EU) |
| Interface Connector | USB 3.2 Gen 1 Type-C, Ethernet RJ45, RS-232/485, SMA (Reverse Polarity) |
